IAME X30 125cc TaG - Complete Engine Package

$3,295.00

Sale Sold out

The X30 has been engineered to provide an innovative yet faithful to tradition engine. The IAME X30 offers modern features, such as the electric starter, the balancer shaft and the water cooling, yet preserving traditional Karting engines aspects, such as the diaphragm carburetor and no power valve. The result is an engine that offers a pure Karting driving experience, combined with ease of use and low maintenance.

Technical Specifications

Engine Type: single cylinder – 2 stroke
Bore: Ø 54.00 mm
Max Bore: Ø 54.28 mm
Stroke: 54.00 mm
Displacement: 123.67cc (125cc max)
Carb. Model: Tillotson HW-27A (Ø 26mm)
Inlet System: reed valve
Lubrication: oil mixture 4% to 6% (24:1 to 16:1)
Ignition System: digital with battery charger
Transmission: dry centrifugal clutch
Cooling System: water cooled
Starting: on-board electric starter
Max Power: 28 Hp (21 Hp ) at 11.750 Rpm
Max Torque: 17 Nm (13Nm) at 10.750 Rpm
Max RPM Limit: 16.000 Rpm (Rpm limiter)

Engine Package Includes

Selettra digital K ignition with pick-up in the stator and generator for battery charging
H.T. coil and vibration dampers
NGK BR9EG sparkplug and resistive spark plug cap
Centrifugal dry clutch group with Z11 detachable sprocket
Tillotson HW-27A Carburetor
Intake silencer with foam air filter
Flexible hose with silicon sheath and springs
Exhaust silencer and exhaust header mod. X30
Starter motor external support
X30 electronic box “C” model - 16.000 RPM
Cables harness with connectors
SSR starter relay
Starter key assembly
Battery support
Velcro strap and dampening rubber pads
Water pump assembly, water pump support, water pump transmission pulley
Water radiator with support
Water hoses and clamps
Thermostat 50°

X30 Documentation

Engine Specs (SKUSA) (PDF 8.3 MB)
Engine Assembly Manual (PDF 5 MB)
Engine Overhaul Manual (PDF 5 MB)
X30 Parts List (PDF 3.3 MB)
